Sound and Audio Circuits

Sound circuits capture, process, generate and reproduce audio — the electrical signals that correspond to sound waves. At one end a microphone acts as a transducer, turning air pressure variations into a small voltage; at the other end a loudspeaker turns an amplified electrical signal back into sound. Between them lie the many circuits that make up audio electronics, including preamplifiers, power amplifiers, tone controls, filters, mixers and oscillators.

A microphone’s output is very weak, so a preamplifier raises it to a usable level before further processing. Power amplifiers then boost the signal enough to drive a loudspeaker, and their design centres on delivering current without distortion and without wasting energy as heat. Filters shape the frequency content of a signal: a tone control or equaliser boosts or cuts bass and treble, while bandpass and notch filters isolate or remove particular frequencies. Mixers combine several audio sources into one.

Other sound circuits generate audio rather than amplify it. Oscillators produce tones for sirens, alarms, doorbells and electronic instruments, and their frequency sets the pitch. Many simple audio projects are built around a single integrated amplifier chip, while more demanding hi-fi designs use discrete transistors or operational amplifiers for low noise and low distortion. Throughout audio design, attention to noise, frequency response and distortion determines the quality of the reproduced sound.

Frequently asked questions

Why is a preamplifier needed before a power amplifier?

Sources such as microphones produce a very small signal. A preamplifier raises it to a standard level and allows tone and volume adjustment before the power amplifier drives the loudspeaker.

What does a tone control do?

A tone control is a simple filter that boosts or cuts particular frequency ranges, such as bass and treble, letting the listener adjust the balance of the sound.

How is an electronic tone or siren produced?

An oscillator circuit generates a repeating waveform at an audio frequency. The frequency sets the pitch, and the waveform is amplified to drive a loudspeaker.
